Without clapboard HEPA high efficiency dust air filter
Introduction:Without clapboard HEPA high efficiency dust air filter Specialty 1. Collecting 0.3 Micron or below particles and used as the terminal filtration. 2. High efficiency pleat 0.2 micron air filter hepa is processed by super fine fiberglass media
We're here to help:
Easy ways to get the answers you need.
Product parameter:
Without clapboard HEPA high efficiency dust air filter
Specialty
1. Collecting 0.3 Micron or below particles and used as the terminal filtration.
2. High efficiency pleat 0.2 micron air filter hepa is processed by super fine fiberglass media or PP media separated by sized paper or aluminum foil with new polyurethane gasket, there is MDF, galvanized steel, stainless steel, aluminum frame available.
3. Each HEPA air filter is individually tested via PSL particle, Using MPPS (DOP Test) laser particle counting device to measure overall efficiency of the filter.
4. It is featured with high efficiency, low resistance, high dust holding, long working life, easy installation.
5. Temperature resistance: 80℃, relative humidity is 80%.
Specification
Size(mm)
| Rated Airflow(m3/h ) | Filter Class(m2) | Dust holding Capacity(g/m2) | Initial Pressure Drop(Pa) | Final Pressure Drop(Pa) | Average Arrestance |
484x484x120 | 390 | 4.4 | 230 | ≤220 | 600 | >99.97% |
610x610x120 | 620 | 7.1 | 370 | ≤220 | 600 | >99.97% |
915x610x120 | 930 | 10.6 | 560 | ≤220 | 600 | >99.97% |
1220x610x120 | 1500 | 14.1 | 740 | ≤220 | 600 | >99.97% |
484x484x150 | 530 | 6.0 | 320 | ≤220 | 600 | >99.97% |
610x610x150 | 1000 | 9.7 | 510 | ≤220 | 600 | >99.97% |
915x610x150 | 1500 | 14.5 | 770 | ≤220 | 600 | >99.97% |
1220x610x150 | 2000 | 19.3 | 1020 | ≤220 | 600 | >99.97% |
484x484x220 | 1000 | 9.8 | 600 | ≤220 | 600 | >99.97% |
610x610x220 | 1600 | 15.8 | 920 | ≤220 | 600 | >99.97% |
915x610x220 | 2300 | 23.7 | 1340 | ≤220 | 600 | >99.97% |
1220x610x220 | 3000 | 31.6 | 1750 | ≤220 | 600 | >99.97% |
Xinxiang Lifeierte Filter Corp.,Ltd （Stock code：837936）is specialized in manufacture of filters ,filter equipment,and environment system . Located in Xinxiang City-the center of Filtration in China.Lefilter has superior R & D team, professional technical team,experienced overseas sales team and perfect after-sales service system.We Lefilter people will try our best to satisfy customers' requirements.The develop philosophy of LEFILTER is “To purify environment,To serve society,To manage faithfully and To oyrsye excellence”!What’s more,there're advanced production line,test machine and R & D department.They also obtained certification like ISO9001, IQNet & CQM,SGS,CNEX etc.
