CC3LG02H13 LG Liquid and Gas Coalescing Filter Cartridges

Nominal Dimensions

• Lengths

  • CC05: 5 in. (127 mm)

  • CC1: 10 in. (254 mm)

  • CC3: 30 in. (762 mm)

  • CS: 40 in. (1016 mm)

• Diameters

  • CC05: 57 mm (2.25 in.)

  • CC1: 70 mm (2.75 in.)

  • CC3: 70 mm (2.75 in.)

  • CS: 152 mm (6 in.)

Operating Conditions and Sizing

• Changeout Differential 0.83 bard (12 psid) + Pressure Clean Differential Pressure

Note:Assembly pressure drop designed to customer specification using P-all LGSIZER2™ software program. Contact P-all for part number and assembly sizing recommendations

Maximum Gas Temperature

• CC05, CC1, CC3LGA, CC3LG0, CS:

  • With water droplets/vapor 60 °C (140 °F)

  • Water droplet/vapor-free 82 °C (180 °F)

• CC3LGB: Water droplet/vapor-free 82.2 °C (180 °F)

1 Other polymers available
2Based on standard P-all Liquid Aerosol Separation Efficiency (LASE) test
3CC05: > 99.99% removal of 0.3 µm DOP aerosol
4CC1, CC3, CS: > 99.99% removal of 0.2 µm NaCl aerosol. > 99.97% removal of 0.3 µm DOP aerosol
