Replacement Parker high flow filter cartridge MFNP005-40N
Introduction:Product parameter: Replacement Parker high flow filter cartridgeMFNP005-40N Micron 1m5m10m15m20m40m70m100m Cartridge Length: 40 (1016mm) Cartridge Max.OD: 6.0(152mm) Filter Medium: Polypropylene Cellulose Melt Blown PP Support: Po
We're here to help:
Easy ways to get the answers you need.
Product parameter:
PARKER MFNP005-40N High Flow Rate Filter profile:
Parker high-flow water filter element provides a solution to effectively replace deep-layer and other 2-1/2" inner diameter filter elements in high-flow situations, such as reverse osmosis prefiltration and similar nominal efficiency requirements. Each Parker ( PAKER) large flow filter element can handle flow rate up to 1300LPM, which significantly reduces the number and size of filter elements. The processing capacity of a PAKER large flow filter element is equivalent to 10 filter elements with an inner diameter of 2-1/2” and a length of 40”. Quantity. The positively charged O-ring seal and the built-in handle make the installation of the filter element fast, safe and convenient.
The Feature of High Flow Rate Filter product :
1.The filter element has large dirt holding capacity and long service life
2.Less replacement times to reduce labor costs
3.The design of the sealed interface reduces the risk of side flow and improves the filtration efficiency
4.Easy to install, low labor cost
5.A wide range of chemical applications can be used in a variety of fields
High Flow Rate Filter technical specifications:
|
Filter material |
polypropylene (PP), glass fiber |
|
Support / diversion layer |
polypropylene |
|
End cover material |
glass fiber reinforced polypropylene |
|
Sealing ring material |
ethylene propylene rubber |
|
Filtration accuracy |
1μm, 4.5μm, 5um, 6μm, 10μm, 20μm, 40μm, 70μm, 100μm |
|
Maximum operating temperature |
82℃ |
|
Maximum pressure drop |
3.4Bar at 82℃ |
|
Recommended maximum filtered water flow |
1300LPM |
PARKER High Flow Rate Water Filter Application areas:
1.RO security filtration, seawater desalination pretreatment
2. Power plant condensate filtration
3. Filtration of raw materials, solvents and water in the biopharmaceutical industry
4.Bottled water, sugar liquid, edible oil, fruit juice, soft drink, milk filtration
5. Paint, ink, CD, magnetic medium, petrochemical industry, refining
6. Microelectronics, film, fiber, resin
