BLYJ Series Portable oil filter car
Introduction:Application: Hydraulic lubrication system refueling and regular maintenance Hydraulic lubrication system bypasss filtration Product Performance: 1. The oil filter cart is an ultra-portable fuel oil filter machine. 2. The machine is easily to
We're here to help:
Easy ways to get the answers you need.
Product parameter:
Application:
Hydraulic lubrication system refueling and regular maintenance
Hydraulic lubrication system bypass’s filtration
Product Performance:
1. The oil filter cart is an ultra-portable fuel oil filter machine.
2. The machine is easily to carry, can fill oil to any hydraulic lubrication equipment in various circumstances and purify the oil.
3. The coarse filtration of suction port can protect the pump and extend the life of the main filter.
4. The precision filter chosen by different users for different precision, and can achieve the desired results.
Technical parameters:
Note: * Secondary precision filter accuracy, such as 003 means 3 um
** The applicable media: generally hydraulic oil BH: water, glycol
V: phosphate ester hydraulic fluids
Hydraulic lubrication system refueling and regular maintenance
Hydraulic lubrication system bypass’s filtration
Product Performance:
1. The oil filter cart is an ultra-portable fuel oil filter machine.
2. The machine is easily to carry, can fill oil to any hydraulic lubrication equipment in various circumstances and purify the oil.
3. The coarse filtration of suction port can protect the pump and extend the life of the main filter.
4. The precision filter chosen by different users for different precision, and can achieve the desired results.
Technical parameters:
| Model | BLYJ-6-*/** | BLYJ-10-*/** | BLYJ-16-*/** |
| Rated flow( L/min) | 6 | 10 | 16 |
| Temperature(°C) | 6-80 | ||
| Recommended viscosity (CSt) | 10-160 | ||
| Rated pressure (Mpa) | 0.4 | ||
| The original pressure loss (Mpa) | ≤0.02 | ||
| First filtration precision before pump (μm) | 40 | ||
| Secondary filtration accuracy after pump (μm) | 3,5,10,20,40 | ||
| Voltage (V) | Three-phase AC380V Two-phase AC220V | ||
| Motor Power (kw) | 0.18 | 0.25 | 0.35 |
| Weight kg) | 13 | 16 | 18 |
| Dimensions(mm) | 350x200x510 | 400x200x510 | 420x200x510 |
Note: * Secondary precision filter accuracy, such as 003 means 3 um
** The applicable media: generally hydraulic oil BH: water, glycol
V: phosphate ester hydraulic fluids
FAQ
Q1: Are you manufacturer?
A: Yes, we are manufacturer , and was public listed successfully in 2016,also our factory is located in Xinxiang City, Henan Province,China. Welcome to visit us!
Q2: How is the quality of the filters?
A: 'Quality is our culture!"
As a result, all of our replacement elements are manufactured rights here in China, under the most rigorous quality standards. Additionally, all of our filter elements carry Seven ISO Standards and we fully guarantee all of our products.
Q3: How do you guarantee the after-sale service?
A: Before shipment, our products are checked one by one. If any problems caused by the product itself, we will supply you the new replaced ones.
Q4: Do you accept OEM?
A: Yes, we can manufacture according to your requirement.
Q5: Can you design filters according to the working condition?
A: Yes. We have professional R&D department , and we can design the more suitable filters for you.
Xinxiang Lifeierte Filter Corp.,Ltd （Stock code：837936）is specialized in manufacture of filters ,filter equipment,and environment system . Located in Xinxiang City-the center of Filtration in China.Lefilter has superior R & D team, professional technical team,experienced overseas sales team and perfect after-sales service system.We Lefilter people will try our best to satisfy customers' requirements.The develop philosophy of LEFILTER is “To purify environment,To serve society,To manage faithfully and To oyrsye excellence”!What’s more,there're advanced production line,test machine and R & D department.They also obtained certification like ISO9001, IQNet & CQM,SGS,CNEX etc.
