ZU-H, QU-H series pressure line filter

Product Description

The filter is installed on the pressure pipeline of the hydraulic system to filter out the mechanical impurities mixed in the hydraulic oil and the colloid,asphalt, carbon residue,etc. produced by the chemical change of the hydraulic oil itself,so as to prevent the occurrence of valve core jamming,the blockage of throttle hole gap and damping hole,and the rapid wear of hydraulic components.
The filter is equipped with a differential pressure transmitting device.When the filter element is polluted and blocked until the differential pressure at the inlet and outlet is 035MPa,it will send a signal that the filter element should be cleaned or replaced to achieve the purpose of protecting the system.
INQUIRY

Technical Parameters

Model	drift diameter (mm)	Flow rate (L/min)	filtration accuracy (μm)	nominal pressure (MPa)	pressure loss (MPa)		transmitter power	weight (Kg)	Model of element	Connect
Model	drift diameter (mm)	Flow rate (L/min)	filtration accuracy (μm)	nominal pressure (MPa)	Initia	Max	transmitter power	weight (Kg)	Model of element	Connect
ZU/QU-H10x*P	15	10	1 3 5 10 20 30	32	0.08	0.35	24V/48W 220V/50W	3.6	HX - 10 X * #	tubular
ZU/QU-H25x*P	15	25			0.08			5.0	HX - 25 x * #
ZU/QU-H40X*P	20	40			0.1			8.0	HX - 40 X * #
ZU/QU-H63x*P	20	63						9.8	HX — 63 x * #
ZU/QU-H100x*P	25	100						12.0	HX - 100 X * #
ZU/QU-H160x*P	32	160			0.12			18.2	HX - 160 X * #
ZU/QU-H250X*FP	40	250			0.12			23.0	HX - 250 x * #	flange type
ZU/QU-H400x*FP	50	400			0.15			133.8	HX - 400 X * #
ZU/QU-H630x*FP	53	630						42.0	HX - 630 X * #
ZU/QU-H800x*FP	53	800						52.0	HX - 800 X * #

Note:*refers to the filtration accuracy, # refers to the filter material. If the medium used is water glycol,the operating pressure is 32Mpa,the nominal flow is 63L/min,the filter material is paper,with transmitter and by-pass valve,the filter model is Zui Bh-h63x*P, filter element model is HX BH-63X*Q.If the filter material is chemical fiber with transmitter,the filter model is qu.bh-63x*Q and the filter element model is HX Bh-63x*Q,the filter material is metal mesh with transmitter,then the filter model is wu-h63x*P and the filter element model is HX - 63x*W.

CATALOG VIDEO

Product Display
Customer Cases
- double druml oil filtration site

  function:hydraulic oil filtrationrate of flow:1000t/h
- pressure pipeline filtration site

  function:hydraulic oil filtrationrate of flow:200t/h
- machining filtration site

  function: oil filtratiionrate of flow:100t/h

DF series high pressure filter

Product Description

The superimposed filter can be directly installed under the electromagnetic directional valve to remove or prevent the mechanical impurities mixed in the hydraulic oil and the colloid and asphaltene produced by the chemical change of the hydraulic oil from entering the electromagnetic directional valve,so as to prevent the instability or jamming of the valve core and the occurrence of faults such as excessive wear of the valve,and maintain the normal operation of the system.It is especially suitable for automatic control system and servo system.

INQUIRY

Application	widely used in hydraulic systems such as heavy machinery,mining machinery and metallurgical machinery.
Filter medium	water and ethylene glycol in hydraulic oil

Technical Parameters

model	drift diameter (mm)	Flow rate (L/min)	filtration accuracy (μm)	nominal pressure (MPa)	pressure loss (MPa)		transmitter power (V/W)	filter element model
model	drift diameter (mm)	Flow rate (L/min)	filtration accuracy (μm)	nominal pressure (MPa)	Initial	Max.	transmitter power (V/W)	filter element model
DF-H30 x *C/Y	6	30	3 5 10	32	<=0.01	0.5	24V/48W 220V/50W	LH0030D*BH3HC
DF-H60 x *C/Y	10	60						LH0060D*BH3HC
DF-H110 X *C/Y	10	110						LH0110D*BH3HC

Connection Size

CATALOG VIDEO
Product Display
Customer Cases
- double druml oil filtration site

  function:hydraulic oil filtrationrate of flow:1000t/h
- pressure pipeline filtration site

  function:hydraulic oil filtrationrate of flow:200t/h
- machining filtration site

  function: oil filtratiionrate of flow:100t/h

RF Return line Filter

Product Description

The filter is used for fine filtration of the return oil of the hydraulic system to filter out metal particles produced by the wear of components in the hydraulic system and rubber impurities of seals and other pollutants,so as to keep the oil flowing back to the oil tank clean.

INQUIRY

Application	widely used in hydraulic systems such as heavy machinery, mining machinery and metallurgical machinery.
Filter medium	water and ethylene glycol in hydraulic oil

Technical Parameters

model	nominal flow rate (L/min)	filtration accuracy (μm)	drift diameter (mm)	nominal pressure (MPa)	pressure loss (MPa)		transmitting device (V/W)		weight (Kg)	filter element model
model	nominal flow rate (L/min)	filtration accuracy (μm)	drift diameter (mm)	nominal pressure (MPa)	Initial	Max.	(V)	(A)	weight (Kg)	filter element model
RF - 60 x * Y/C	60	1 3 5 10 20	20	1	W0.07	0.35	12 24 36 220	2.5 2 1.5 0.25	0.4	LH0060R* BN/HC
RF - 110 x * Y/C	110		20						0.9	LH0110R* BN/HC
RF - 160 x * Y/C	160		40						1.1	LH0160R* BN/HC
RF - 240 x * Y/C	240		40						1.8	LH0240R* BN/HC
RF - 330 x * Y/C	330		50						2.3	LH0330R* BN/HC
RF - 500 x * Y/C	500		50						3.2	LH0500R* BN/HC
RF - 660 x * Y/C	660		80						4.1	LH0660R* BN/HC
RF - 850 x * Y/C	850		80						13	LH0850R* BN/HC
RF - 950 x * Y/C	950		90						20	LH0950R* BN/HC
RF - 1300 x * Y/C	1300		100						41.5	LH1300R* BN/HC

Note:*refers to filtration accuracy.If the medium is water-glycol,nominal flow rate is 160L/min,filtration accuracy is 10μm,with CYB- I transmitter,the filter model is RF . BH-160 x 10Y,and the filter element model is LH0160R010BN/HC.

CATALOG VIDEO

Product Display
Customer Cases
- double druml oil filtration site

  function:hydraulic oil filtrationrate of flow:1000t/h
- pressure pipeline filtration site

  function:hydraulic oil filtrationrate of flow:200t/h
- machining filtration site

  function: oil filtratiionrate of flow:100t/h

SRLF Duplex return line filters

Product Description

The filter is composed of two single cylinder drippers and two position six way directional valve.It has the advantages of simple structure and convenient use.It is equipped with by-pass valve and filter element pollution blockage transmitter to ensure the safety of the system.
In the working process,when the filter element of the single cylinder filter is blocked to a certain extent and needs to be cleaned or replaced,stop the main engine to replace the filter element,which not only wastes time,but also can not meet the needs of the continuous operation of the main engine.The double cylinder filter effectively solves the defects of the single cylinder filter,and the filter element can be cleaned or replaced without shutdown to ensure the normal and continuous operation of the main engine.

INQUIRY

SRLF Duplex return line filters Lefilter

Application	widely used in hydraulic systems such as heavy machinery, mining machinery and metallurgical machinery.
Filter medium	water and ethylene glycol in hydraulic oil

Technical Parameters

Model	Flow rate (L/min)	filtration accuracy (μm)	Dia (mm)	Press. (MPa)	Pressure loss(MPa) (MPa)		Indicator power	Weight (Kg)	Model of element
Model	Flow rate (L/min)	filtration accuracy (μm)	Dia (mm)	Press. (MPa)	Initia	Max	Indicator power	Weight (Kg)	Model of element
SRLF-60x*P	60	1 3 5 10 20 30	25	1.6	<=0.08	0.35	24V/48W 220V/50W	13.2	SFX-60 X *
SRLF-110x*P	110		25					13.7	SFX-110 X *
SRLF-160x*P	160		40					29.5	SFX-160 X *
SRLF-240x*P	240		40					32	SFX-240 x *
SRLF-330 x*P	330		50					52.5	SFX-330 x *
SRLF-500 x*P	500		50					58.5	SFX-500 x *
SRLF-660 x*P	660		80					77	SFX-660 x *
SRLF-850x*P	850		80					81	SFX-850 x *
SRLF-950x*P	950		100					112	SFX-950 x *
SRLF-1300 x*P	1300		100					121	SFX-1300 x *

Note:*refers to filtering accuracy.If the medium used is water glycol,the use pressure is l6MPa,the nominal flow is 110L/min,the filtering accuracy is 10um,and the transmitter is provided.Then the filter model is SRLF Bh-110x10p,filter element model SFX BH-110x10。
